Hikvision DS-7104HGHI-M1/T 4-Channel DVR
720P\1080P Lite 4-ch 1 HDD Two-way Audio DVR
Offer Price
₹ 3700.00 /- only
Inclusive of all taxes
GST Invoice Benefit: Get GST Invoice And Save Up To 28% on Business Purchases.
- Availability: in stock
Free Delivery
1 Year Product Warranty
After Sales Support
Secure Transection
Product Description
The Hikvision DS-7104HGHI-M1/T is a highly efficient 4-Channel Mini 1U Digital Video Recorder engineered to streamline modern high-definition analog and IP video streams
We offer this cutting-edge surveillance unit integrated with deep learning-based Motion Detection 2.0 enabled by default across all analog channels, accurately classifying human and vehicle targets while filtering out environmental noise
The system features advanced H.265 Pro+ video compression technology that dramatically improves encoding performance and substantially reduces long-term data storage costs
It supports a hybrid adaptive environment welcoming HDTVI, AHD, CVI, CVBS, and IP video inputs, allowing up to 5 channels of IP network cameras up to 2 MP resolution
Equipped with a native 1 SATA storage interface supporting drive capacities up to 4 TB, it enables continuous 24/7 logging alongside smart search functions for highly efficient video playback
The system boasts complete multi-channel utility, featuring Audio over Coaxial cabling and advanced HDTVI two-way audio technology across all available channels to eliminate separate audio wire installations
Are you looking to install a premium Hikvision CCTV camera in Surat or configure a smart multi-camera business setup? We provide precision multi-channel setup, professional coaxial mapping, sound sync testing, and remote live mobile app tracking configurations
Technical Specification
| Video Compression | H.265 Pro+ / H.265 Pro / H.265 / H.264+ / H.264 |
| Analog Video Input | 4-Channel BNC interface (supporting coaxitron connection) |
| Supported Analog Inputs | HDTVI, AHD, HDCVI, CVBS adaptive inputs |
| IP Video Input | 1-ch (up to 5-ch), up to 2 MP resolution (H.265+/H.265/H.264+/H.264) |
| Encoding Resolution | 1080p Lite / 720p Lite / 720p / WD1 / 4CIF / VGA / CIF |
| Main Stream Frame Rate | 1080p Lite/720p Lite/WD1/4CIF/VGA/CIF @ 25 fps (P) / 30 fps (N) |
| Video Bitrate Capacity | 32 Kbps to 4 Mbps stream processing |
| Audio Feature Setup | Audio over Coaxial Cable & All Channels HDTVI Two-Way Audio |
| Audio Input Interface | 1-ch RCA (2.0 Vp-p, 1 KΩ) & 4-ch via Coaxial Cable |
| Synchronous Playback | 4-Channel simultaneous local playback |
| SATA Storage Interface | 1 Interface port for digital hard drive |
| Smart Analytics | Deep learning-based Motion Detection 2.0 (Human/Vehicle classification) |
| Storage Capacity Max | Up to 4 TB maximum storage capacity for each disk |
| Video Display Output | 1-ch HDMI & 1-ch VGA simultaneous output (up to 1920x1080) |
| Network Interface Port | 1, RJ45 10/100 Mbps self-adaptive Ethernet interface |
| Remote Connections Max | Up to 32 remote concurrent data connections |
| USB Interfaces | Rear panel: 2 x USB 2.0 connectivity ports |
| Power Supply Input | 12 VDC, 1.5 A operating power |
| Power Consumption | Less than or equal to 10 Watts (Without HDD connected) |
| Operating Conditions | -10 °C to 55 °C, Humidity 10% to 90% (non-condensing) |
| Chassis Dimensions | 200 × 200 × 48 mm (7.9 × 7.9 × 1.9 inch) |
| Net Product Weight | Less than or equal to 0.8 kg (Without internal HDD installed) |
Support & Downloads
PDF Catalogue: Download
Warranty: 2 year Product Warranty
